| Minimum Order Quantity: | 1 PC |
|---|---|
| Packaging Details: | wooden cases, pallets or as per customer request |
| Delivery Time: | 30 days after receiving down payment |
| Payment Terms: | L/C, T/T, Western Union |
| Body Material: | CF8M |
|---|
stainless steel PTFE CF8M floating ball valve
Stainless steel ball valve is widely used in petroleum refining, long-distance pipeline, chemical industry, paper, pharmaceutical, water conservancy, electric power, municipal, steel and other industries.
Specifications
floating ball valve range:
1.Production Size:1/2"~10".DN15~DN250
2.Pressure:150LB,300LB,600LB,900LB
floating ball valve standard
1.Design Standard:ANSI 608
2.Face to Face:ASME B16.10
3.Flange Standard:ASME B16.10
4.Testing Standard:API 598
floating ball valve main material of parts:
1.Body:CF3,CF3M,CF8,CF8M
2.Bonnet:CF3,CF3M,CF8,CF8M
3.Stem:2Cr13/SS304/SS316/Carbon Steel
4.Ball:CF3,CF3M,CF8,CF8M
5.Packing:PTFE
6.Seat:PTFE,RPTFE
7.Washer:PTFE
8.Handle:ASTM A536 65-45-12,A351 CF8,A351 CF8M
Product show
